Concealed Hinge Drill Guide Adjustable Aluminum Cabinet Hardware Jig

Complete cabinet and woodworking drilling tasks with a concealed hinge drill guide designed for controlled hole placement. This multifunctional cabinet hardware jig pairs with a power drill and uses a strong clamp to secure the board during drilling. It supports 1.0 in and 1.4 in (26 mm and 35 mm) hinge holes and accommodates boards from 0.1–3.0 in (3–75 mm) thick. Adjustable elevation control and included positioning components support a range of drilling and alignment tasks for DIY woodworking projects.

Key Features

• 26/35 mm Hinge Hole Support: Drills 1.0 in and 1.4 in (26 mm and 35 mm) concealed hinge holes.

• Strong Board Clamp: Helps hold wood boards securely for cleaner drilling.

• Wide Board Thickness Capacity: Accommodates boards from 0.1–3.0 in (3–75 mm) thick.

• Adjustable Elevation: Knob adjusts positioning for boards 0.4–1.0 in (10–25 mm) thick.

• Multiple Positioning Functions: Includes front limiters and U-shaped groove alignment for guided drilling.

• CNC-Machined Aluminum Alloy: Anodized aluminum alloy construction provides a robust working platform.



Specifications

• Material: Aluminum alloy

• Color: Red

• Compatibility: Power drills

• Hinge Hole Diameters: 1.0 in / 1.4 in (26 mm / 35 mm)

• Board Thickness Capacity: 0.1–3.0 in (3–75 mm)

• Adjustable Board Thickness Range: 0.4–1.0 in (10–25 mm)


• Package Includes: Multifunctional woodworking drilling machine, 26/35 mm hinge hole drilling guide, U-shaped groove alignment tool, adjustable control knob, positive front limiter



Why Choose Our Concealed Hinge Drill Guide Adjustable Aluminum Cabinet Hardware Jig
This woodworking drill guide combines board clamping, adjustable positioning, and multiple drilling guides in one setup. Its aluminum alloy construction and adjustable controls make it practical for precise cabinet and woodworking projects.

Perfect For
Suitable for DIY woodworking projects that require concealed hinge drilling, centered holes, or U-shaped groove alignment on compatible wood boards.

Drill Cabinet Hardware with Better Control
Set up your board, adjust the guide, and complete supported hinge and alignment drilling tasks with a versatile tool made for repeatable woodworking setups.
