Vector Network Analyzer – 10 kHz–1.5 GHz Antenna Tester with 2.8 in Touchscreen, TDR, ABS Case & Calibration Standards

Take a closer look at your antenna setup and make testing more informative. This vector network analyzer covers a stated frequency range of 10 kHz to 1.5 GHz for antenna and RF measurements. Its touchscreen displays S-parameters, SWR, phase, delay, and Smith charts. With TDR analysis and compatible Android screen viewing, this portable antenna tester offers several ways to examine your results.

Key Features
• Multiple measurement views help you assess antenna and RF characteristics.
• TDR analysis adds time-domain information to your testing workflow.
• Compatible Android screen viewing offers a larger display through a Type-C connection.
• Included calibration standards and RF cables help you prepare your measurement setup.

Why Choose Our Vector Network Analyzer?
Compared with a basic SWR meter, this instrument provides additional information through S-parameter, phase, delay, and Smith chart views. Its ABS casing, touchscreen, and supplied calibration accessories combine practical handling with versatile measurement functions.

Perfect For
Ideal for amateur radio enthusiasts, electronics hobbyists, and technicians evaluating compatible antennas and RF components. Suitable for HF, VHF, and UHF projects within the specified frequency range.

Product Specifications
• Casing material: ABS
• PCB dimensions: Approx 2.13 × 3.37 × 0.43 in, excluding connectors and switches
• Measurement frequency: 10 kHz–1.5 GHz
• Display: 2.8 in TFT touchscreen, 320 × 240 resolution
• RF output: −13 dBm, maximum −9 dBm
• Frequency accuracy: <0.5 ppm
• Measurement range: 70 dB at 50 kHz–300 MHz / 50 dB at 300–600 MHz
• Extended measurement range: 40 dB at 600–900 MHz with extended firmware enabled
• Port SWR: <1.1
• USB interface: Type-C
• Communication mode: CDC serial
• Power supply: USB 5 V, 120 mA
• Built-in battery: 650 mAh
• Maximum charging current: 0.8 A
• Calibration points: 101, fixed
• Scanning points: 101, fixed
• Display traces: 4
• Markers: 4
• Saved settings: 5
• Measurement functions: S-parameters / SWR / Phase / Delay / Smith chart / TDR
• Battery status: Displayed on the interface
• Phone display compatibility: Supported Android phones; iPhone not supported

Package Includes
• 1 × Analyzer with touchscreen and built-in battery
• 2 × 7.87 in SMA male-to-male RG174 RF cables
• 2 × SMA female-to-female connectors
• 1 × SHORT calibration standard
• 1 × OPEN calibration standard
• 1 × LOAD calibration standard
• 1 × USB Type-C data cable
• 1 × Type-C-to-Type-C cable
• 1 × Touch paddle

Expand your testing toolkit with the Vector Network Analyzer. Order yours for convenient calibration and a more detailed view of your antenna and RF measurements.
