Vector Network Analyzer – 10 kHz–1.5 GHz Antenna Tester with Touchscreen, TDR, ABS Case & Calibration Standards

Bring more insight to your antenna projects with measurement results you can view and compare. This vector network analyzer covers a stated frequency range of 10 kHz to 1.5 GHz. Its 2.8 in touchscreen displays S-parameters, SWR, phase, delay, and Smith charts. With TDR analysis and compatible Android screen viewing, this portable antenna tester offers convenient ways to examine your RF setup.

Key Features
• Multiple measurement views help you assess antenna and RF characteristics.
• TDR analysis adds time-domain information to your testing workflow.
• Compatible Android screen viewing provides a larger display option through Type-C.
• Included calibration standards and RF cables help you prepare for measurements.

Why Choose Our Vector Network Analyzer?
Compared with a basic SWR meter, this instrument provides additional information through S-parameter, phase, delay, and Smith chart views. Its touchscreen, ABS casing, and supplied calibration accessories combine practical handling with versatile testing functions.

Perfect For
Ideal for amateur radio enthusiasts, electronics hobbyists, and technicians evaluating compatible antennas and RF components. Suitable for HF, VHF, and UHF projects within the specified frequency range.

Product Specifications
• Detailed specifications apply to: 2.8 in version
• Casing material: ABS
• PCB dimensions: 2.13 × 3.37 × 0.43 in, excluding connectors and switches
• Measurement frequency: 10 kHz–1.5 GHz
• Display: 2.8 in TFT touchscreen, 320 × 240 resolution
• RF output: −13 dBm, maximum −9 dBm
• Frequency accuracy: <0.5 ppm
• Measurement range: 70 dB at 50 kHz–300 MHz / 50 dB at 300–600 MHz
• Extended measurement range: 40 dB at 600–900 MHz with extended firmware enabled
• Port SWR: <1.1
• USB interface: Type-C
• Communication mode: CDC serial
• Power supply: USB 5 V, 120 mA
• Built-in battery: 650 mAh
• Maximum charging current: 0.8 A
• Calibration points: 101, fixed
• Scanning points: 101, fixed
• Display traces: 4
• Markers: 4
• Saved settings: 5
• Measurement functions: S-parameters / SWR / Phase / Delay / Smith chart / TDR
• Battery status: Displayed on the interface
• Phone display compatibility: Supported Android phones; iPhone not supported

Package Includes
• 1 × Analyzer with 2.8 in touchscreen and built-in battery
• 2 × 7.87 in SMA male-to-male RG174 RF cables
• 2 × SMA female-to-female connectors
• 1 × SHORT calibration standard
• 1 × OPEN calibration standard
• 1 × LOAD calibration standard
• 1 × USB Type-C data cable
• 1 × Type-C-to-Type-C cable
• 1 × Touch paddle

Expand your testing toolkit with the Vector Network Analyzer. Order yours for convenient calibration and a more detailed view of your antenna measurements.
